| 型號 | 最大扭矩范圍 /Nm | 最高轉速 /rpm | 精度 | 產品尺寸 /mm | 重量 /kg | 內置彈簧伸縮長度/mm | 批頭快換 | 工具控制器 | 工具電纜 |
| PTC-ASF-4500M-0-HM0-000 | 0.05-0.45 | 1500 |
標準偏差 ±2.5% |
135×46×57 | 0.51 | - | HM4 | OPT-STC-C1-V1 -50W |
可選 5m/10m/15m 直頭或彎頭線纜 |
| PTC-ASF-0009N-0-H10-000 | 0.09-0.9 | 1500 | 162.6×46×57 | 0.81 | - | Hex 1/4" | OPT-STC-C1-V1 -100W | ||
| PTC-ASF-0009N-0-H10-015(L) | 0.09-0.9 | 1500 | 206×46×57 | 0.78 | 15 | Hex 1/4" | |||
| PTC-ASF-0030N-0-H10-000 | 0.5-3 | 950 | 236×46×57 | 1.35 | - | Hex 1/4" | |||
| PTC-ASF-0030N-0-H10-030(L) | 0.5-3 | 950 | 302×46×57 | 1.32 | 30 | Hex 1/4" | |||
| PTC-ASF-0065N-0-H10-000 | 1.5-6.5 | 450 | 236×46×57 | 1.35 | - | Hex 1/4" | |||
| PTC-ASF-0065N-0-H10-030(L) | 1.5-6.5 | 450 | 302×46×57 | 1.36 | 30 | Hex 1/4" | |||
| PTC-ASF-0070N-0-H10-030(L) | 1-7 | 830 | 361×70×82 | 2.99 | 30 | Hex 1/4" | OPT-STC-C1-V1 -200W | ||
| PTC-ASF-0120N-0-H10-030(L) | 4-12 | 900 | 361×70×82 | 3.42 | 30 | Hex 1/4" | OPT-STC-C1-V1 -400W | ||
| PTC-ASF-0180N-0-S20-030(L) | 3-18 | 180 | 321×46×57 | 1.66 | 30 | Square 3/8" | OPT-STC-C1-V1 -100W | ||
| PTC-ASF-0270N-0-S20-030(L) | 5-27 | 450 | 361×70×82 | 3.46 | 30 | Square 3/8" | OPT-STC-C1-V1 -400W | ||
| PTC-ASF-0520N-0-S30-050(L) | 12-52 | 240 | 450×70×82 | 4.51 | 50 | Square 1/2" | |||
| PTC-ASF-1050N-0-S30-050(L) | 20-105 | 230 | 498×100×108 | 9.69 | 50 | Square 1/2" |
